Single Row Full Complement Cylindrical Roller Bearings

Single row full complement cylindrical roller bearings are designed to accommodate very high radial loads in combination with moderate speeds. The bearings incorporate a maximum number of rollers as they are not equipped with a cage. Having two integral flanges on the inner ring and one flange on the outer ring, NCF design bearings can accommodate axial displacement in one direction. A retaining ring on the outer ring holds the bearing together. The retaining ring should not be loaded axially during operation.

Keywords:

Cylindrical Roller Bearings

Category:

Cylindrical Roller Bearings

+8615610177274

northseiko@bbkbearing.com

E-mail

Related Products

Message

Product Details

Product Details

Detailed pictures

Parameter table

Bearing Number	d mm	D mm	B mm
NCF 3004 CV	20	42	16
NCF 3005 CV	25	47	16
NJG 2305 VH	25	62	24
NCF 3006 CV	30	55	19
NJG 2306 VH	30	72	27
NCF 3007 CV	35	62	20
NCF 3008 CV	40	68	21
NJG 2308 VH	40	90	33
NCF 3009 CV	45	75	23
NJG 2309 VH	45	100	36
NJG 309 VH	45	100	25
NCF 3010 CV	50	80	23
NCF 3011 CV	55	90	26
NCF 2912 CV	60	85	16
NCF 2913 CV	65	90	16
NCF 3013 CV	65	100	26
NJG 2313 VH	65	140	48
NCF 2914 CV	70	100	19
NCF 3014 CV	70	110	30
NCF 2915 CV	75	105	19
NCF 3015 CV	75	115	30
NCF 2916 CV	80	110	19
NCF 3016 CV	80	125	34
NCF 2917 CV	85	120	22
NCF 3017 CV	85	130	34
NCF 2918 CV	90	125	22
NCF 3018 CV	90	140	37
NCF 2920 CV	100	140	24
NJG 2320 VH	100	215	73
NCF 2922 CV	110	150	24
NCF 3022 CV	110	170	45
NCF 2224V	120	215	58
NCF 2924 CV	120	165	27
NCF 3024 CV	120	180	46
NCF 2926 CV	130	180	30
NCF 3026 CV	130	200	52
NCF 2928 CV	140	190	30
NCF 3028 CV	140	210	53
NCF 2930 CV	150	210	36
NCF 3030 CV	150	225	56
NCF 2932 CV	160	220	36
NCF 3032 CV	160	240	60
NCF 2234 V	170	310	86
NCF 2934 CV	170	230	36
NCF 3034 CV	170	260	67
NCF 2936 CV	180	250	42
NCF 3036 CV	180	280	74
NCF 2938 CV	190	260	42
NCF 3038 CV	190	290	75
NCF 2940 CV	200	280	48
NCF 3040 CV	200	310	82
NJG 2340 VH	200	420	138
NCF 2944 CV	220	300	48
NCF 3044 CV	220	340	90
NCF 2948 CV	240	320	48
NCF 3048 CV	240	360	92
NCF 1852V	260	320	28
NCF 2952 CV	260	360	60
NCF 3052 CV	260	400	104
NCF 1856 V	280	350	33
