KR NUKR CF series

Cam followers (stud-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a needle roller bearing with a threaded solid stud instead of an inner ring. They have a thick-walled outer ring with a crowned running surface and are supplied ready-to-mount. A narrow gap between the outer ring and the adjacent components forms a gap-type seal. The bearings can be relubricated via the stud.

Keywords:

Needle roller Bearings

Category:

Needle roller Bearings

+8615610177274

northseiko@bbkbearing.com

E-mail

Related Products

Message

Product Details

Product Details

Cam follower (stud-type track roller) with relubrication feature
Cam followers (stud-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a needle roller bearing with a threaded solid stud instead of an inner ring. They have a thick-walled outer ring with a crowned running surface and are supplied ready-to-mount. A narrow gap between the outer ring and the adjacent components forms a gap-type seal. The bearings can be relubricated via the stud.
High radial load carrying capacity
Accommodate axial loads due to skew or tilting
Long service life
Easy to mount
Sealed for increased reliability, with relubrication feature

Detailed pictures

Parameter table

Bearing Number	D mm	d mm	B mm	C mm
NUKR 35 XA	35	16	52	18
NUKR 40 XA	40	18	58	20
NUKR 47 XA	47	20	66	24
NUKR 52 XA	52	20	66	24
NUKR 62 XA	62	24	80	28
KR 22	22	10	36.2	12
KR 26	26	10	36.2	12
KRVE 30 PP	30	15	40.2	14
KR 32	32	12	40.2	14
KR 35	35	16	52.1	18
KR 47	47	20	66.1	24
KR 52	52	20	66.1	24
KRV52 PP	52	20	66.1	24
KR 62	62	24	80.1	29
PWKRE 62.2RS	62	28	80	28
KRV 26	26	10	36.2	12
KR 30	30	12	40.2	14
KR 72	72	24	80.1	29
PWKR 72.2RS	72	24	80	28
PWKRE 72.2RS	72	28	80	28
KR 80	80	30	100	35
KRE 80 PP	80	35	100	35

IKO				D mm	d mm	C mm	G
CF 3 BR	CF 3 B	CF 3 BUUR	CF 3 BUU	10	3	7	M 3*0.5
CF 4 BR	CF 4 B	CF 4 BUUR	CF 4 BUU	12	4	8	M4*0.7
CF 5 BR	CF 5B	CF 5 BUUR	CF 5 BUU	13	5	9	M 5*0.8
CF 6 BR	CF 6B	CF 6 BUUR	CF 6 BUU	16	6	11	M 6*1
CF 8 BR	CF 8B	CF 8 BUUR	CF 8 BUU	19	8	11	M8*1.25
CF 10 BR	CF 10 B	CF 10 BUUR	CF 10 BUU	22	10	12	M10*1.25
CF 10-1 BR	CF 10-1 B	CF 10 BUUR	CF 10-1 BUU	26	10	12	M10*1.25
CF 12 BR	CF 12 B	CF 12 BUUR	CF 12 BUU	30	12	14	M12*1.5
CF 12-1 BR	CF 12-1 B	CF 12-1 BUUR	CF 12-1 BUU	32	12	14	M12*1.5
CF 16 BR	CF 16 B	CF 16 BUUR	CF 16 BUU	35	16	18	M16*1.5
CF 18 BR	CF 18 B	CF 18 BUUR	CF 18 BUU	40	18	20	M18*1.5
CF 20 BR	CF 20 B	CF 20 BUUR	CF 20 BUU	52	20	24	M20*1.5
CF 20-1 BR	CF 20-1 B	CF 20-1 BUUR	CF 20-1 BUU	47	20	24	M20*1.5
CF 24 BR	CF 24 B	CF 24 BUUR	CF 24 BUU	62	24	29	M24*1.5
CF 24-1 BR	CF 24-1 B	CF 24-1 BUUR	CF 24-1 BUU	72	24	29	M24*1.5
CF 30 BR	CF 30 B	CF 30 BUUR	CF 30 BUU	80	30	35	M30*1.5
CF 30-1 BR	CF 30-1 B	CF 30-1 BUUR	CF 30-1 BUU	85	30	35	M30*1.5
CF 30-2 BR	CF 30-2 B	CF 30-2 BUUR	CF 30-2 BUU	90	30	35	M30*1.5
